FlowExpert’s innovative design makes advances flow chemistry accessible. A true state of the art microreactor platform that integrates great usability with new opportunities for high level flow chemistry.
Configurations
FlowExpert’s innovative design integrates great usability with new opportunities for advanced flow chemistry. FutureChemistry offers several standard FlowExpert configurations for multiple application.
Benefits of the FlowExpert
- Plug ‘n Play
- Advanced system with low learning curve
- Automated synthesis
- cGMP compliant workflow
- Direct coupling to GC/HPLC intruments
- Works under inert conditions
- Excellent mixing at microliter scale
- High reproducibility
Technical specifications for basic configuration
| Temperature zones | 1 |
| Temperature range | -10 to 200 °C (Accuracy +/- 0.5 °C |
| Reactor volumes | 0 ? 100 μL |
| Number of reagents / substrates | 3 |
| Reaction time | 0.5 ? 20 min |
| AC Power | 110-120 V / 220-240 V, 50-60 Hz |
Microreactor holder
| Materials | PEEK and stainless steel |
| Fluidic connection | Flat bottom ferrule |
| Microreactor compatibility | FutureChemistry Microreactor cartridge |
| Dimensions (L x W x H) | 80 x 44 x 11.5 mm |
