SDTGA500은 석탄, 코크스 및 다양한 고체 바이오매스 연료의 수분 함량을 측정하는 데 사용할 수 있습니다.
1 batch 당 배치당 12개 샘플을 높은 효율로 측정합니다.
Highlights
- Overall lid open designed, improve the heat dissipation,shorten the waiting time between two batches sample test, high test efficiency.
- High quality stainless steel is adopted in furnace internal wall, uniform heating can be realized with good heat resistance property and reflectivity.
- Automatic testing,sample weight real time display,several analyzers in one computer are available.
- Self-diagnosis, self-protection function; Stable operation, easy maintenance.
- Network and balance connection are available by standard interface RS232.
Specification
|
Description |
SDTGA500 |
|---|---|
| Max. Sample |
12 samples |
| Sample mass |
(User -defined sample mass is also available) |
| Sample particle |
moisture on air dried basis ≤0.2mm Φ6 total moisture ≤6mm Φ3 total moisture ≤3mm |
| Furnace temperature |
Ambient〜150℃(Light wave heating) |
| Analysis time |
|
| Max.Power |
1.5kW |
| Power requirement |
AC 220 V，50/60 Hz |
