Excellent detection limits, at ppb level for most elements
Wide linear dynamic range, from ppb to percentage
Real time operating monitor by software with build-in protection logic program
Application
Rare earth metal
Silicon materials, magnetic materials processing industry
Metallurgical industry: analysis of impurity elements influencing the quality of metal materials. Water quality control
Petrochemical: measurements of more than 30 elements in crude oil
Pharmacy, hygiene, agriculture, environmental protection, commodities and food industry
Performance Characteristics
Advanced optical design with a fully illuminated holographic grating, with spectral interference correction and high light throughput for improved detection limits
Wide wavelength range
Computer controlled plasma platform optimizes the viewing position to reduce interferences, improve SNR and minimize background emissions
Software controlled flow of carrier gas, plasma gas and auxiliary gas provide real time monitor as well as highly stability of flux
The torch position can be adjusted electrically, and the software has the automatic torch position optimization function
Sample waste drained by peristaltic pump ensures stable sample flow rate; Fast pump mode improves productivity
The brand new robust free-running, 40.68 MHz RF generator that delivers unsurpassed performance
Rapid and accurate automatic coupling system ensures the ultimate power transfer efficiency and stability
Specifications
Solid State Power (RF)
Frequency
40.68MHz
Frequency stability
≤0.05%
Output power
800W ~ 1600W, continuously adjustable with power efficiency more than 65%
Output power stability
<0.1%
Inlet system
Automizer
concentric atomizer
Multichannel 12-roller peristaltic pump, with less data fluctuation caused by different physical properties of samples
Mass flowrate controller for carrier gas flow control. It can be regulated by 0.01L continuously. Mass flowrate controller for cooling gas and auxiliary gas flow control. It can be regulated by 0.1L continuously.
Optical System
Optical type
Echelle and prism dimensional spectroscopic system
CCD
1024 x 1024 pixels (single pixel area of 24x 24 μm)
Resolution
0.007nm at 200nm
Grating specification
52.67 L/mm and 50mm x 100mm of ruling area
Spectral range
165-900nm
Focal length
400 mm
Technical Specifications
Suitable sample content range
Liquid sample: 0.01ppm~ several thousands ppm
Solid or powder sample: 0.001%~70%
