Capstan Bollard Grips
G255SK Tensile Wire Cord Capstan Grip 10 kN (2,250 lbf)
PRODUCT INFORMATION
| Model# | G255SK |
|---|---|
| Force | 10 kN (2,250 lbf) |
| Thickness | 4 mm (0.16 in) |
| Sample Width | 25 mm (1 in) |
Capstan grips are designed for tensile tests on samples that are round cross section such as wire, cord, twine, yarn, thread, medical sutures, tubes and rope.
- Rated to 10 kN (2,250 lbf)
- Maximum sample Dia. 4 mm (0.157 in)
- 26mm (1.02 in) Dia. Capstan
- Serrated Jaws
- 15.9 mm (0.625 in) Dia. female cup adapter with a hole for a 8 mm dia. cross pin
Note: Optional adapters or mechanical connections available for all test machines.
