ISO 20482 Erichsen Deep Draw Test Fixture for Metals | GISO20482-145
PRODUCT INFORMATION
| Model# | GISO20482-145 |
|---|---|
| Force | Made to standard |
| Width | Made to standard |
| Diameter | Made to standard |
GISO20482-145 Erichsen Deep Draw Test Fixture tests metallic sheets and strips having a thickness from 0,1 mm up to 2 mm and a width of 90 mm or greater to undergo plastic deformation in stretch forming.
- Tests in accordance with specifications stated in ISO 20482
- Outfitted with a 60 mm female cup adapter with a hole for a cross pin
- 20 mm probe diameter
- 33 mm ring opening diameter
- Adapters are available for your test machine
Another Model also available
| GDIN50101-2-145 | DIN 50101 | Metals |
