Interferometer

Cube-corner Michelson interferometer

Beam splitter

Multilayer Ge coated KBr

Detector

Room temperature DLATGS module (standard),

Temperature stabilized, high sensitivity DLATGS module (optional)

IR Source

High intensity, long lifetime, air-cooled IR source

Wavenumber Range

7800cm^-1~350cm^-1

Resolution

0.85 cm^-1

Signal to noise ratio

Better than 20,000:1

(RMS value, at 2100cm^-1 ~ 2000cm^-1 or 2100cm^-1 ~ 2200cm^-1, resolution: 4cm^-1, detector: DLATGS, 1 minute data collection)

Wavenumber Accuracy

±0.01 cm^-1

Scanning Speed

Microprocessor control, different scanning speed selectable.

Software

Main FTOS Suite software workstation, compatible to all version Windows OS,

Various specialized functional software modules (optional)

Communication

Ethernet interface (standard), WIFI wireless communication (optional)

Data Output

Standard data format, report generation and output

Status Diagnosis

Power on self check, real-time temperature and humidity monitoring and reminders

Certification

FDA 21 CFR Part11 compliance,IQ/OQ/PQ(Optional)
